1- A clinical level microscope for routine applications in
medical, veterinary and university labs.
2- Crisp, High Resolution Images at an Affordable Price
SRMB-540 Series features our Plan Achromat Infinity
objectives which are renowned for crisp, high contrast
images with outstanding resolution. Modular in design the
SRB-540 boasts options for entry level fluorescence
applications, phase contrast, darkfield and simple
polarization.
3- Ease of Viewing, Maximum Flexibility
With 22mm field of view eyepieces and an eyepoint height
that is adjustable, it can be raised 35mm by rotating the
eyepiece tubes up 180° to accommodate the needs of various
users.
4- Sharp, High Resolution Optics
These Infinity plan objectives provide users with best in
class high resolution, high contrast objectives.
5- Rackless Stage
The rackless, scratch resistant rectangular stage has
low-positioned X-Y coaxial controls.
Specification:
|
|
SRB-540
|
|
|
Optical System
|
Infinity Optical
System, f = 200mm,
Anti-Mold
|
●
|
|
Viewing Head
|
Binocular head,
Siedentopf type,
inclined 30°;
interpupillary distance
adjustment 47-75mm,
360° rotatable;
Eyepoint height is
adjustable and can be
raised 35mm when the
interpupillary distance
is 64mm by rotating the
eyepiece tubes up 180°
to accommodate the
needs of various users.
|
●
|
|
Trinocular head,
Siedentopf type,
inclined 30°;
interpupillary distance
adjustment 47-75mm,
360° rotatable;
Eyepoint height is
adjustable and can be
raised 35mm when the
interpupillary distance
is 64mm by rotating the
eyepiece tubes up 180°
to accommodate the
needs of various users.
|
○
|
|
Eyepiece
|
WF10x focusable
eyepieces, 22mm field
of view;eyepieces are
locked-in to prevent
classroom tampering.
Eyepiece accepts a
Ø26.5mm reticle,
Eyepiece Tube Diameter
30mm
|
●
|
|
Wide Field Eyepiece
EW15×/16
|
○
|
|
Wide Field Eyepiece
EW20×/12
|
○
|
|
Nosepiece
|
Rear facing Quadruple,
ball bearing nosepiece
with positiveclick
stops to ensure
parcentration
|
●
|
|
Rear facing Quintuple,
ball bearing nosepiece
with positiveclick
stops to ensure
parcentration
|
○
|
|
Objective
|
Standard configuration
includes Infinity Plan
achromat 4x,10x, 40xR
and 100xR oil
|
●
|
|
Infinite Plan
Achromatic Objective
20×，60×
|
○
|
|
Condenser
|
N.A. 1.25 Abbe
Condenser with aperture
diaphragm and position
guide markings for each
objective and filter
holder
|
●
|
|
Focusing System
|
Coaxial Coarse and Fine
Adjustment, Fine
Division 0.002mm,
Coarse Stroke 37.7mm
per Rotation,
Fine Stroke 0.2mm per
Rotation, Moving Range
24mm
Coaxial focusing system
with adjustable tension
control and upper limit
stop to prevent
accidentaldamage to
slides; all metal
gears, brass fine focus
gear
|
●
|
|
Stage
|
Rackless, scratch
resistant rectangular
stage, 216 x 150mm
surface area with 78 x
54mm cross travelusing
low-postion X-Y coaxial
control knobs
|
●
|
|
Illumination
|
3 watt LED (20,000 hour
rated life), with field
diaphragm
|
●
|
|
12V/30W Halogen Lamp,
Brightness Adjustable
|
○
|
|
12V/20W Halogen Lamp,
Brightness Adjustable
|
○
|
|
Accessories
|
Photo Attachment
|
○
|
|
Video Adapter
|
C Mount 0.4×
|
○
|
|
C Mount 0.5×
|
○
|
|
Polarization Attachment
|
○
|
|
Phase Contrast Kit
|
○
|
|
Dark Field Attachment
|
Dark-field Condenser
(Dry)
|
○
|
|
Dark-field Condenser
(Oil)
|
○
|
|
Kohler Illumination
|
○
|
|
Epi-Fluorescent
Attachment
|
○
|
|
